RAGLAN 4 AXLES LIVE BOTTOM 48'' LENGTH

LENGHT48'-0 "
WIDTH102 "
HEIGHT135 "
WEIGHTAround 9 500 kg
CAPACITY55 yd³
DESIGNFlat side-wall construction @ 48” high Polished
TAILGATEGreasable hinges, air locks, c/w air gate lift
FRONT DOOR20'' wide and 36'' high (driver) and the driver's side steps of approx.
AXLES TRIDEMIntraxx 30000 lbs , Pro torque nuts, Bigbearing
STEERING AXLEIMT
HUBS & DRUMSDura hub and drums standard
BRAKES16.5 X 7 X ¾’’ Q-Brakes, CM-20, non-Asbestos lining
A.B.S.2S / 1M (Haldex)
CAMS10 spines c/w cam enclosures
BOOSTER30-30 TSE avec slack adjuster (haldex)
SUSPENSION'S CONTROLLERManuel inside the control box
TIRES TRIDEMRoad Master RM234 | 11 R22,5
TIRESRoad Master RM234 | 11 R22,5
RIMS TRIDEM8,25 x 22,5 en Alcoa Aluminum (inside and outside)
RIMS ''AUTO-VIREUR''12,25 x 22,5 Alcoa Aluminum (inside/outside)
LANDING GEARJOST, two-speed with crank on drivers’ side
PICK UP PLATE18'' King Pin with 3/8" Plate at 49" height Holland-KP-1-809-BF MU
BELT-A-MATICRed and Green light front road side
TAKE-UPSAutomatic mounted at the front; adjustable tracking
DRIVE DRUMS22” dia. c/w 3/8 lagging
PLANTERYRR Canada 2400
LIGHTSLED c/w side signal
FENDERSStainless steel contoured over each axle c/w mud flaps
PAINTSteel components sandblasted, primed, and painted one (1) colour GREY
ALUMINUM WASHEDPolished aluminum sheet with standard aluminum reinforcement
CALCIUM TANKAluminum tank install on driver's side
PRICECall us for more information!
CONTACT(450) 688-3555 / Ask for François or Sylvain!
PriceInformation request for this trailer

No parts available online for this trailer. Please contact us at 450-688-3555 for parts in stock.
